A compact planar ring-electrode assembly for embedded EC/TDS products. Its exposed surface is easy to rinse and the mechanical form is suited to integrated molding and appliance structures.
Probes & AccessoriesCurrent model
TFE-304-M6
Planar Ring-electrode Temperature Probe | water quality measurement
Easy-clean planar ring electrode with integrated temperature sensing for molded product integration.
Original manufacturer · Factory-direct supply
Questions go straight to the source
Ask about parameters, interfaces, calibration, versions, customization or volume supply. The answer does not need to pass through layers of resellers.
- In-house R&DOptics, sensor-interface electronics, algorithms, firmware and mechanical integration are developed as one product system.
- Production capabilityFrom prototype and pilot build to assembly, functional testing and volume delivery, production follows the product team’s technical definition.
- Quality traceabilityModel, specification, firmware or hardware version and test requirements remain connected, reducing ambiguity between sales claims and delivered goods.
Overview
Why this product
Easy-clean planar ring electrode with integrated temperature sensing for molded product integration.
A compact planar ring-electrode assembly for embedded EC/TDS products. Its exposed surface is easy to rinse and the mechanical form is suited to integrated molding and appliance structures.
Easy-clean planar ring electrode with integrated temperature sensing for molded product integration.
- ✓Planar ring-electrode design
- ✓Integrated temperature sensor
- ✓Easy-clean exposed electrode face
- ✓Designed for stable mechanical integration
- ✓Can be used in secondary insert molding
Verified technical detail
Information to provide for selection · Calibration, validation and maintenance
Easy-clean planar ring electrode with integrated temperature sensing for molded product integration.
Interface / Supply
Electrode and temperature leads · Host circuit dependent
Measurement Range / Accuracy
EC / TDS application dependent · Electrode and circuit dependent
Installation and commissioning
Keep creepage surfaces clean and avoid contamination between electrodes.
Verified technical detail
Engineering and integration
The official Chinese document is currently shared by every language version.
Engineering and integration
- 01
Planar ring electrode geometry for compact wetted assemblies.
- 01
Integrated temperature-sensing option supports compensated measurement.
- 01
Mechanical dimensions are defined by the official TFE-304-M6 drawing.
- 01
Measurement range and accuracy are determined by the paired ASIC, cell constant and calibration.
Installation and commissioning
- ✓
Keep creepage surfaces clean and avoid contamination between electrodes.
- ✓
Confirm sealing, material compatibility and insertion depth in the final housing.
- ✓
Calibrate after the electrode is installed in its production mechanical structure.
Product and document views
Public documents
TFE-304-M6 中文尺寸图Applications
